Project |
Parameter |
|
Maximum pipe bending capacity |
Φ76×4mm |
|
Maximum feeding stroke（b） |
2500mm（Standard） |
|
Feeding method |
Direct delivery or sandwich delivery |
|
Maximum bending radius |
R300mm |
|
Maximum bending Angle |
185° |
|
The number of elbow pipe files can be set |
200 |
|
Bending pipe speed |
MAX40°/S |
|
Pipe rotation speed |
MAX120°/S |
|
Feeding speed |
MAX500mm/S |
|
Elbow Angle |
±1° |
|
Rotating tube Angle |
±0.1° |
|
Feeding length |
±0.1° |
|
Rotary tube servo motor |
1KW |
|
Feeding servo motor |
2KW |
|
Oil pump motor |
11KW |
|
Machine external dimensions |
5200 X 1150 X1700 mm |
|
Machine weight |
2800KG |
