Number |
Name |
Unit |
Parameter |
Remarks |
|
|
1 |
Maximum bending pipe diameter |
mm |
Φ130*6Carbon steel |
|
|
|
2 |
Maximum bending radius |
mm |
550 |
According to customer requirements |
|
|
3 |
Minimum bending radius |
mm |
According to the pipe diameter |
|
|
|
4 |
Maximum feeding length |
mm |
3000 |
According to customer requirements |
|
|
5 |
Feeding method |
|
|
Optional |
|
|
6 |
Maximum bending Angle |
Degree |
185° |
|
|
|
7 |
Use the controller |
|
PLC |
|
|
|
8 |
The number of bends can be set for each pipe fitting |
a |
20 |
According to customer requirements |
|
|
9 |
Working speed |
Bending pipe speed |
Deg/sec |
50 |
Adjustable |
|
Pipe rotation speed |
Deg/sec |
120 |
Adjustable |
||
|
Feeding speed |
Deg/mm |
500 |
Adjustable |
||
|
10 |
Precision |
Feeding accuracy |
mm |
±0.1 |
|
|
Tube rotation accuracy |
Degree |
±0.1 |
|
||
|
Bending accuracy |
Degree |
±1° |
|
||
|
11 |
Power of the feeding servo motor |
W |
5000 |
|
|
|
12 |
Power of corner servo motor |
W |
3000 |
|
|
|
13 |
Motor power |
Kw |
22 |
|
|
|
14 |
Maximum pressure |
MPa |
14 |
Adjustable |
|
|
15 |
Hydraulic system control |
|
Electromagnetic directional control valve |
|
|
|
16 |
Fuel tank capacity |
L |
400 |
|
|
|
17 |
Machine weight |
Kg |
9800 |
|
|
|
18 |
Machine size |
cm |
6800*1300*1700 |
|
|
