Name

Units

Parameters

Note

Maximum bending pipe diameter

mm

Φ89×6mm Carbon steel

Bending radius 2D or above

Maximum bending radius

mm

350

Can be done according to the customer's requirements

Minimum bending radius

mm

According to the pipe diameter

Effective core penetration length

mm

3000

Maximum bending angle

Degree

190

Use the controller

Microcomputer

Maximum pressure

MPa

16

Adjustable

Hydraulic system control

Electromagnetic directional control valve

Motor power

KW

11

Fuel tank capacity

L

250

Machine weight

Kg

3000

Machine size

mm

5500*850*1100
