Project

Parameters

Maximum bending pipe capacity

Φ76×4mm

Maximum feeding stroke（b）

2500mm（Standard）

Delivery method

Direct delivery or cross-delivery

Maximum bending radius

R300mm

Maximum bending angle

185°

The number of bend pipe files can be set.

200

Bent pipe speed

MAX40 degree/second

Flow rate of the transfer pipe

MAX120 degree/second

Delivery speed

MAX500mm/S

Bent pipe angle

±1 degree

Angle of the elbow joint

±0.1 degree

Delivery length

±0.1 degree

Rotating tube servo motor

1KW

Delivery servo motor

2KW

Oil pump motor

11KW

Machine dimensions

5200 X 1150 X1700 mm

Machine weight

2800KG（About）
